Steel Roller Shutter Product Series

1. Insulated Steel Roller Shutter

Product Overview

The insulated steel roller shutter is an innovative composite door system constructed with double-layer galvanized steel sheets filled with high-density polyurethane foam. The total panel thickness is approximately 22mm, with each steel layer being 0.4-0.5mm thick. Manufactured through advanced continuous foaming technology, it perfectly combines the strength of steel with the insulation properties of foam.

Key Features

Excellent Thermal Insulation: Polyurethane foam layer density ≥60kg/m³, thermal conductivity ≤0.02W/(m·K), significantly reducing heat transfer and improving energy efficiency.

Superior Sound Insulation: Double-layer steel sheets and foam layer create multiple sound barriers, with noise reduction up to 8-12 decibels when combined with sealed guide rails and bottom gaskets.

Enhanced Structural Design: Streamlined panel cross-section with wind-resistant side locks provides wind pressure resistance up to level 10.

Intelligent Control System: Standard remote and manual dual operation, with optional Bluetooth and WiFi smart control modules supporting multiple opening methods.

Technical Parameters

  • Total panel thickness: 22±1mm

  • Steel sheet thickness: Outer 0.5mm/Inner 0.4mm

  • Foam density: 60-65kg/m³

  • Wind resistance: Levels 8-10

  • Thermal coefficient: K≤2.0W/(m²·K)

  • Operating temperature: -30℃ to +60℃

  • Color options: RAL standard colors, custom colors available

Applications

Ideal for shopping malls, supermarkets, hotels, office buildings, industrial plants, cold chain logistics, and automotive 4S centers where high requirements for insulation, soundproofing, and security are needed.


2. Standard Steel Roller Shutter

Product Overview

A cost-effective single-layer roller shutter made from 0.8-1.2mm high-quality galvanized steel sheets, precision-rolled into shape. This product features simple structure, easy installation, and excellent value, meeting basic protection and separation needs.

Key Features

Durable Construction: High-quality cold-rolled galvanized steel with electrostatic powder coating, offering corrosion and aging resistance.

Smooth Operation: High-strength aluminum alloy guide rails with nylon rollers ensure quiet, smooth movement.

Safety & Security: Equipped with anti-prying devices and safety edges, with optional electronic locks and alarm systems.

Easy Maintenance: Modular design with standardized components simplifies repair and replacement.

Technical Parameters

  • Panel thickness: 0.8mm/1.0mm/1.2mm options

  • Surface treatment: Galvanized + polyester powder coating

  • Opening speed: 0.2-0.3m/s

  • Operating temperature: -20℃ to +50℃

  • Service life: ≥50,000 opening cycles

  • Motor power: 370W-750W (based on size requirements)

Applications

Suitable for garages, warehouses, workshops, retail shops, parking lots, and residential building entrances where thermal insulation is not critical and cost-effectiveness is prioritized.


3. Stainless Steel Roller Shutter

Product Overview

A premium roller shutter made from 304/201 stainless steel, offering exceptional corrosion resistance and aesthetic appeal. Available in various surface finishes including brushed, mirror, and titanium-plated, combining functionality with decorative value.

Key Features

Superior Corrosion Resistance: 304 stainless steel performs excellently in chloride-rich environments, ideal for coastal and humid areas.

Elegant Appearance: Strong metallic texture with multiple surface treatment options enhances architectural aesthetics.

Hygienic & Clean: Smooth, non-porous surface easy to clean and disinfect, meeting food and pharmaceutical industry standards.

Long Service Life: Can last over 15 years under normal conditions.

Technical Parameters

  • Material grade: 304 (8% nickel)/201 (1% nickel)

  • Thickness options: 0.6mm/0.8mm/1.0mm

  • Surface finishes: 2B/BA/No.4/HL/Titanium-plated

  • Corrosion resistance: 304 passes 48-hour neutral salt spray test

  • Cleanliness: Complies with GMP cleanroom standards

  • Fire rating: Class A non-combustible

Special Options

  • Antimicrobial coating

  • Fingerprint-resistant treatment

  • Nano self-cleaning coating

  • Fire-rated upgrade (1-2 hours fire resistance)

Applications

Food processing plants, pharmaceutical facilities, hospitals, laboratories, coastal buildings, high-end commercial centers, and corrosive industrial environments.


Product Selection Guide

Feature

Insulated Steel Roller Shutter

Standard Steel Roller Shutter

Stainless Steel Roller Shutter

Thermal Insulation

★★★★★

★★☆☆☆

★★☆☆☆

Sound Insulation

★★★★★

★★★☆☆

★★★☆☆

Corrosion Resistance

★★★★☆

★★★☆☆

★★★★★

Service Life

8-12 years

5-8 years

12-15 years

Initial Investment

Higher

Economical

Premium

Maintenance Cost

Lower

Low

Very Low

Suitable Environment

Temperature-controlled areas

Standard environments

Corrosive environments


After-Sales Service

  • Warranty: 5 years for motor, 3 years for shutter

  • 24-hour technical support

  • Free design consultation

  • Professional installation team

  • Regular maintenance services

The steel roller shutter product series, with its diverse performance characteristics and wide applicability, has become an essential component of modern architecture. We provide professional selection advice and customized solutions based on your specific environmental conditions and functional requirements.
