Brief description:Our High-speed Spiral Doors represent the pinnacle of industrial entrance technology. Featuring a unique aluminum spiral guide rail, the panels retract without touching, eliminating friction and wear. With opening speeds up to $2.0\, \text{m/s}$ and a high-density PU-insulated core, this door provides superior thermal control and durability for high-traffic environments. It is the perfect blend of security, speed, and long-term reliability.
Product
The Premium Solution for Speed, Security, and Thermal Efficiency
Our High-Speed Spiral Doors represent the pinnacle of industrial entrance engineering. Designed for high-traffic environments, these doors combine the security of a rigid aluminum door with the speed of a high-speed fabric door. Utilizing a patented non-contact spiral track, the door panels never touch during operation, eliminating friction and ensuring a whisper-quiet, long-lasting performance.
【Reinforced Strength】1.5mm Heavy-Duty Steel Frame
While the industry standard is often 1.0mm, we utilize 1.5mm reinforced cold-rolled or stainless steel for our frames and guide rails. This adds significant structural weight and stability, ensuring the door remains rock-solid even during high-speed, high-frequency operation.
【Elite Insulation】High-Density PU Foam Core
The 40mm/50mm thick panels are injected with high-density Polyurethane (PU) foam ($45\text{ kg/m}^3$). This provides superior thermal insulation, noise reduction, and a wind resistance rating of up to Class 4 (resisting winds up to 32 m/s).
【Contactless Spiral Technology】Zero Friction
The specialized aluminum spiral circular track ensures that door panels remain separated as they roll up. This prevents scratches on the surface coating, reduces noise, and extends the mechanical lifespan to over 1 million cycles.
【Smart Servo Control】Precision & Speed
Powered by an advanced industrial servo motor, the door can reach speeds of up to 2.5 m/s. The soft-start and soft-stop features ensure smooth movement, protecting the motor and hardware from wear and tear.
| Component | Specification & Material |
| Frame & Guide Rail | 1.5mm Reinforced Steel (Standard) |
| Panel Thickness | 40mm or 50mm (Double-skinned Aluminum + PU) |
| Aluminum Skin | 0.7mm - 1.5mm (Customizable based on security needs) |
| Operating Speed | 0.8 - 2.5 m/s (Adjustable via Frequency Inverter) |
| Motor System | High-precision Industrial Servo System ($0.75\text{kW} - 1.5\text{kW}$) |
| Wind Resistance | Class 4 (Up to 117 kg/m² / 12-grade Gale) |
| Sealing System | Multi-layer EPDM Weather Stripping (Top, Sides, Bottom) |
| Safety Features | Full-height Safety Light Curtain + Wireless Safety Edge |
| Cycle Rating | Tested for 1,000,000+ maintenance-free operations |
Logistics & Warehousing: Maximizes throughput and minimizes waiting time for forklifts.
Automotive Manufacturing: High-speed access for production lines with a clean, professional look.
Cold Storage & Food Processing: Maintains internal temperatures and prevents energy loss.
Commercial Parking Garages: Offers rapid, silent entry with high-level anti-theft security.
